Industrial RFID tags for technical applications and demanding environments. Dipole offers a wide range of RFID tags in UHF, HF, LF and NFC technologies, designed for applications that require higher mechanical, thermal or chemical resistance. They are built to withstand impacts, temperature, humidity and washing processes, with on-metal options and different mounting systems such as technical adhesive, screws, rivets or cable ties. Available in various formats and memory capacities, RFID tags make it possible to identify assets, containers, tools and parts with high durability. Stable readings, long service life and reliable traceability for industry, logistics, healthcare and laundry applications.
RFID Tag Avery Dennison Twist U9XM
The Avery Dennison Twist U9XM has been designed to provide support throughout the supply chain, from start to finish. This tag is primarily used in the retail, logistics, and automotive sectors, as well as in many other industries.
It can be applied to various surfaces, such as glass, wood, plastic, and all kinds of non-metallic products. The label's reading capacity can reach up to 12 meters, depending on the environment and the applied material.
The exceptional performance of this tag results in a higher number of reads and writes compared to other tags in its competition.
Product description RFID Tag Avery Dennison Twist U9XM
This product has a square shape with dimensions of 23 x 23 mm. It operates efficiently in extreme and fluctuating temperature conditions, with an operating range spanning from -40 °C to 85 °C without any issues.
This tag complies with international quality and performance standards ISO 18000-63 EPC class 1 Gen 2, ensuring its proper functioning in complex and changing environments. Additionally, like all RFID products from Avery Dennison, it is manufactured to the highest industry quality standards.
This tag has a rectangular shape with dimensions of 70 x 14 mm. It operates effectively within a temperature range from -40°C to 85°C. Furthermore, it is available in two different models: dry inlay and label.
This tag complies with international quality and performance standards ISO 18000-63 EPC class 1 Gen 2, ensuring its optimal functionality even in demanding environments. Additionally, like all Avery Dennison RFID products, it is manufactured to the highest industry quality standards.
Product Codes:
Dry Inlay: 3009486 / IL-609337
Label: 3009485 / IL-609334
The tag can be applied to a wide variety of surfaces, such as wood, cardboard, paper, plastic, glass, and all types of non-metallic products. Depending on the environment and surface of application, the label can be read from distances of up to 15 meters.
This label is manufactured to the highest industry quality standards, just like all RFID products from Avery Dennison, ensuring its proper performance in challenging environments and compliance with international quality and performance standards ISO 18000-63 EPC class 1 Gen 2.
Product Code:
Wet Inlay: 3009493 / IL-609531
The composition of this tag allows it to have a UHF frequency range of 860 - 960 MHz. Additionally, it has dimensions of 44 x 28 mm, making it a product with a rectangular and compact structure. It is available in Dry Inlay, Wet Inlay, and Label formats.
This product meets the international standard ISO 18000-63, EPC Class 1 Gen 2, which means it complies with the most demanding standards in the industrial and RFID communication systems, and it also performs excellently in challenging environments.
Product Code:
Dry Inlay: 3008000 / IL-603995
Wet Inlay: 3007992 / IL-603988
Label: 3007993 / IL-603989
The dimensions of this product are 44 x 28 mm, and it has a UHF frequency range of 860 - 960 MHz. Moreover, it functions smoothly on surfaces such as wood, glass, various types of plastics, and non-metallic materials.
Like all RFID products from Avery Dennison, Eagle NXP Ucode 8 tags are manufactured to the highest industry quality standards and comply with ISO 18000-63 Type C. Additionally, they have EPC Class 1 Gen 2 memory, which provides high performance in complex environments.
Product Code:
Dry Inlay: 3007014 / IL-603372
Label/Sticker: 3007016 / IL-603373
This product has a UHF frequency range of 860-960 MHz and dimensions of 33 x 18 mm. These features allow it to be read at a distance of up to 11 meters, depending on the applied surfaces and the environment.
This tag complies with the international standards of quality and performance ISO 18000-63 EPC class 1 Gen 2, confirming its proper operation in complex environments. Additionally, like all Avery Dennison RFID products, it is manufactured following the highest industry quality standards.
Product Code:
Wet Inlay: 3007174 / IL-603472
Label: 3007175 / IL-603473
The Avery Dennison Smartrac Accessory M730 UHF RFID tags have a compact size of 33 x 15 mm, making them easy to convert into an RFID label for end applications such as glasses, jewelry, cosmetics, pharmaceutical products, etc.
This tag complies with the international quality and performance standards ISO 18000-63 EPC class 1 Gen 2, ensuring its proper functioning in complex environments. Furthermore, like all RFID products from Avery Dennison, it is manufactured following the highest industry quality standards.
Product code:
Dry Inlay: 3008300 / IL-604218
Wet Inlay: 3008304 / IL-600040
Label: 3008305 / IL-604223
In technical terms, this RFID gateway operates on the UHF frequency and is equipped with a 4-port or 2-port UHF RFID reader ETSI (865-868 MHz) FCC (902~928 MHz). The 4 or 2 universal antennas offer a gain of 8.5 dBi, ensuring exceptional performance and high read efficiency of over 99%.
Competitive advantages:
High read reliability
Record movement data in real time and without human intervention
Automation of logistic processes
Ease of use
Addressability
Improved efficiency and error reduction
Guaranteed traceability
The Cubic RS-1100 is made of aluminum and consists of four universal RFID antennas, along with a four-port RFID reader. Additionally, it includes an application software that can be integrated with any management or ERP system, enabling task automation and reducing errors in inventory management. It also facilitates efficient management of goods receiving and dispatching. Preferred applications and uses of Cubic RFID include:
Receptions
Shipments
Picking
Logistics processes
Plastic containers
Cardboard boxes
Product Code:
Dipole Cubic: RS-100-4P
Dipole's priority has been that the customer can have the most important information about their business at a glance and in real time, with a very intuitive and visual Dashboard. In addition, our software allows you to easily configure all the antennas and readers to adjust the RFID readings as needed.
Some of the benefits of Lama software:
Identification of products throughout the process
Real-time data updates
Easy management of RFID records
Easy hardware configuration
Configuration of alerts according to customer KPIs
Full integration with any type of ERP
Possibility of downloading and saving all the information generated in the way that best suits the client.
If you want to know more about Dipole's RFID Lama software, please contact us and we will explain much more.
