Industrial RFID tags for technical applications and demanding environments. Dipole offers a wide range of RFID tags in UHF, HF, LF and NFC technologies, designed for applications that require higher mechanical, thermal or chemical resistance. They are built to withstand impacts, temperature, humidity and washing processes, with on-metal options and different mounting systems such as technical adhesive, screws, rivets or cable ties. Available in various formats and memory capacities, RFID tags make it possible to identify assets, containers, tools and parts with high durability. Stable readings, long service life and reliable traceability for industry, logistics, healthcare and laundry applications.
RFID Tag Avery Dennison AD-554r6-B
The UHF AD-554r6-B tag has been designed primarily for individual baggage tracking in the aviation sector. Its composition allows it to withstand and operate at peak performance, from check-in to retrieval on the conveyor belt.
It can be detected from any angle due to almost the entire tag being covered in aluminum, making it easier to capture the signal. In addition, the tag can be applied to various surfaces such as wood, plastic, fabric, and non-metallic materials.
It comes equipped with the latest generation chip, the Impinj Monza R6-B, which has a 96-bit EPC memory and a 96-bit TID memory.
Product description RFID Tag Avery Dennison AD-554r6-B
The rectangular shape gives the tag dimensions of 38 x 76 mm and is available in Dry Inlay and Wet Inlay formats. Moreover, depending on the environment and the material where it is applied, it has the ability to be read at a distance of 17 meters. Additionally, it operates within a UHF frequency range of 860 to 960 MHz.
Like all RFID products from Avery Dennison, the AD-554r6-B tags are manufactured to the highest industry quality and performance standards, complying with the requirements of ISO 18000-63 Type C.
This tag operates in a UHF frequency range of 860 - 960 MHz and has dimensions of 38 x 76 mm. Thanks to its composition and design, it has a reading range of up to 20 meters on different types of surfaces. It functions perfectly within temperatures ranging from -40 °C to 85 °C.
All Avery Dennison products adhere to the highest quality standards for the industry: ISO 18000-63 Type C, which specifies the parameters that RFID devices must comply with.
Product Code:
Dry Inlay: RF602234 / IL-604494
Wet Inlay: RF602236 / IL-605627
This product operates in the UHF frequency band of 860 - 960 MHz and has dimensions of 94 x 24 mm. It is available in Wet Inlay and Label/Sticker formats and, depending on the environment and surface type where it is applied, such as wood, plastic, glass, and non-metallic materials, it can be read at a distance of up to 16 meters.
Like all Avery Dennison RFID products, the Dogbone NXP UCODE 7 tags are ISO 18000-63 Type C certified, which means they have been manufactured following the highest industry quality standards.
Product Code:
Wet Inlay: 3003020 / IL-602772
Label/Sticker: 3003021 / IL-602773
The Dogbone UCODE G2iL operates in the UHF Global frequency band of 860-960 MHz and has dimensions of 97 x 27 mm. Its robust and durable design allows it to function in demanding environments and adhere to difficult-to-label surfaces such as wood or glass.
The tag complies with international standards of quality and performance ISO 18000-63 EPC Class 1 Gen 2, ensuring its proper functioning in complex environments. Additionally, like all NXP RFID products, it is manufactured following the highest industry quality standards.
The Dogbone UCODE G2iL is available in different configurations, offering a wide range of options to suit the specific needs of each business.
Product Code:
Wet Inlay: 3002037 / IL-602611
Label/Sticker: 3002038 / IL-602612
The Dogbone M730 operates in the UHF Global frequency band 860-960 and has dimensions of 97 x 27 mm. Its robust and resistant design allows it to function in demanding environments and adhere to difficult-to-label surfaces, such as wood or glass.
This tag complies with international standards for quality and performance ISO 18000-63 EPC Class 1 Gen 2, ensuring its proper functioning in complex environments. Additionally, like all RFID products from Avery Dennison, it is manufactured following the highest industry quality standards.
The Dogbone M730 is available in different configurations, offering a wide range of options to suit the specific needs of each business.
Product code:
Dry Inlay: 3008223 / IL-604163
Wet Inlay: 3008445 / IL-604318
Label: 3008054 / IL-604042
The label adhesives are available in all ranges, from permanent to removable, allowing for a wide range of applications.
Dipole manufactures Standard RFID tags with a wide variety of sizes and are ideal for thermal printers or printers with ribbon. They are customizable in all features such as EPC memory, material (paper, cardboard, polyamide, polyethylene, etc.), a variety of adhesives (permanent, removable, for liquids, etc.), or by adding an EAS system.
At Dipole, we offer different delivery formats for greater convenience according to customer needs, and we ship worldwide.
Regarding technical specifications, the RFID tags from the Dipole PRO family operate in the UHF frequency range (860 - 960 MHz) and use IC from the renowned brand Impinj. The EPC memory varies depending on the chosen IC family, providing flexible data storage options. Manufactured with high-quality polyester, these tags offer exceptional durability and a surface suitable for thermal transfer printing.
Complying with ISO 18000-6C Class 1 Generation 2 standards, the Dipole PRO family tags guarantee reliable compatibility and performance in a wide variety of applications. Additionally, they come equipped with high-strength adhesive, ensuring a durable and secure attachment.
RFID Tags Smartrac WEB Monza R6 inlay is designed for the unique identification of textile or electronic products. These inlays are particularly used with great success in the textile industry, providing high performance reads and reliability regardless of the chips orientation and are also used in apparel hangtags.
Product code:
Dry inlay: 3006088
Label / sticker: 3006074
The AD-173u8 tag features the UCODE 8 chip by NXP, with 128 bits of EPC memory and a 96-bit Tag Identifier (TID). The product is available in Label/Sticker format and performs optimally in temperatures ranging from -40 °C to 85 °C.
Like all RFID products by Avery Dennison, the AD-173u8 labels are manufactured to the highest industry quality standards and comply with ISO 18000-63 Type C.
Product code:
Label/Sticker: RF100478 / IL-603737
The dimensions of this item are 50 x 50 mm. It has a UHF frequency range of 860 to 960 MHz and is equipped with the Monza 4D chip from Impinj, which has a 128-bit EPC memory and a 32-bit user memory. Its composition and design provide the capability of being read at a distance of up to 10 meters.
This item meets the international quality and performance requirements of ISO 18000-63 EPC Class 1 Gen 2, ensuring its proper functioning in changing and complex environments. Additionally, it is manufactured following the highest industry quality standards, like all RFID products from Avery Dennison.
Product code:
Wet Inlay: 3002015 / IL-602603
The Zebra ZD621R has a 4-inch print width and features a 4.3-inch color LCD screen for interacting with its user-friendly configuration menus, which guide the user step by step during material loading and calibration. It has a print resolution of 203 dpi or 300 dpi (optional), and it operates on the Link-OS operating system. It supports identifiers compatible with UHF EPC Gen 2 V2, ISO/IEC 18000-63, and RAIN RFID protocols.
It has compact dimensions of only 26.7 cm x 20.2 cm x 19.2 cm, making it a portable printer with its long-lasting battery. It weighs 2.5 kg.
Product codes:
ZD6A142-30EFR2EZ
ZD6A142-31EFR2EZ
ZD6A143-30EFR2EZ
ZD6A143-30ELR2EZ
The Zebra ZT620 series of RFID printers have the following features:
Tags compatible with UHF EPC Gen 2 V2, ISO/IEC 18000-63 and RAIN RFID protocols
Adaptive Encoding Technology automatically selects the optimal encoding settings
Supports industry standards and multi-vendor chip serializations
You can record the user memory and perform permanentblock according to ATA Spec 2000 regulations
Allow users to track performance with RFID job monitoring tools
Applications can be very diverse: Shipping and receiving, Semi-finished and finished product traceability, Document and medical record management, Product identification/serial numbers, Inventory management, Asset tracking, Cross-dock, Receiving/location labelling, Order picking/packaging, etc.
The Zebra ZT610 series of RFID printers have the following features:
Tags compatible with UHF EPC Gen 2 V2, ISO/IEC 18000-63 and RAIN RFID protocols
Adaptive Encoding Technology automatically selects the optimal encoding settings
Supports industry standards and multivendor chip serializations
You can record the user memory and perform permanent block according to ATA Spec 2000 regulations
Allow users to track performance with RFID job monitoring tools
Applications can be very diverse: Shipping and receiving, Semi-finished and finished product traceability, Document and medical record management, Product identification/serial numbers, inventory management, Asset tracking, Cross-dock, Receiving/location labelling, order picking/packaging, etc.
Dipole's priority has been that the customer can have the most important information about their business at a glance and in real time, with a very intuitive and visual Dashboard. In addition, our software allows you to easily configure all the antennas and readers to adjust the RFID readings as needed.
Some of the benefits of Lama software:
Identification of products throughout the process
Real-time data updates
Easy management of RFID records
Easy hardware configuration
Configuration of alerts according to customer KPIs
Full integration with any type of ERP
Possibility of downloading and saving all the information generated in the way that best suits the client.
If you want to know more about Dipole's RFID Lama software, please contact us and we will explain much more.
