RFID Tags

Industrial RFID tags for technical applications and demanding environments. Dipole offers a wide range of RFID tags in UHF, HF, LF and NFC technologies, designed for applications that require higher mechanical, thermal or chemical resistance. They are built to withstand impacts, temperature, humidity and washing processes, with on-metal options and different mounting systems such as technical adhesive, screws, rivets or cable ties. Available in various formats and memory capacities, RFID tags make it possible to identify assets, containers, tools and parts with high durability. Stable readings, long service life and reliable traceability for industry, logistics, healthcare and laundry applications.

RFID tag Smartrac Belt Impinj Monza R6P

The RFID tags Avery Dennison Smartrac Belt Impinj Monza R6P are highly useful in the textile and industrial sectors. They have been designed for individual product identification, logistics process control, and management.

They are equipped with the Impinj Monza R6-P chip. This chip has a feature that allows the tag to self-adjust efficiently and diversely, ensuring optimal performance in every circumstance.

The Monza R6-P inlay offers additional user memory, a deactivation function, and easy access to the memory to change the tag's information if necessary.

Download datasheet double_arrow

Product description RFID tag Smartrac Belt Impinj Monza R6P

This product is available in Dry Inlay, Wet Inlay, and Label/Sticker formats, with a standard dimension of 70 x 10 mm that varies depending on the format. It operates in the UHF frequency range of 860 - 960 MHz.

The tag complies with international quality and performance standards ISO 18000-63 EPC Class 1 Gen 2, ensuring its proper functioning in complex and diverse environments. Additionally, like all Avery Dennison products, they are manufactured following the highest industry quality standards in RFID technology.

Product code:

Dry Inlay: 3005067 / IL-602871

Wet Inlay: 3005068 / IL-602872 (73 x 13 mm)

Label/Sticker: 3005066 / IL-602870 (73 x 17 mm)

UHF

Inlays and Tags

Impinj Monza R6-P

-40 °C to 85 °C / -40 °F to 185 °F

Wood, Plastic, Non Metal, Glass

Label / Sticker, Wet Inlay, Dry Inlay

ISO 18000-63, EPC Class 1 Gen 2

128 bits

UHF Global 860-960 MHz

73mm × 13mm

2.87in × 0.51in
