RFID Antenna Zebra AN620

The AN620 antenna from the manufacturer Zebra Technologies is a stylish antenna that helps save space with its flat and efficient design. The outer casing is elegantly designed and discreet enough to blend in with corporate spaces, yet strong enough to withstand indoor industrial environments.

It has a very simple mounting system and is a perfect complement to Zebra's fixed RFID readers. It is ideal for use on wall mount, door mount, under counter, above counter, as an RFID pad, on shelves, at the point of sale, or places that have limited space like a jewelry counter.

Download datasheet double_arrow

Product description RFID Antenna Zebra AN620

The Zebra AN620 is IP54 certified for environmental sealing so it can be used in conditions where there is a lot of dust in the environment without worrying that performance will be affected. It uses the 865 – 868 MHz UHF RFID frequency for the European Union and the: 902 – 928 MHz for the United States. It has a left-hand circular polarization and an N-type female connector.

The body of this antenna is made of Kydex, a very resistant type of thermoplastic acrylic based on polyvinyl chloride to guarantee the long life of this product. It measures 39.1 cm x 27.5 cm x 1.2 cm and weighs 1 kg.

The operating temperature specified by the manufacturer is -20ºC to +55ºC.

Product code:

ETSI: AN620-SCL71130EU

UHF

6 Watts

75°

Left-hand Circular

7 dBi

-20 °C to 55 °C / -4 °F to 131 °F

IP54

UHF FCC 902-928 MHz, UHF ETSI 865-868 MHz

N Male

391mm × 275mm × 12mm

15.39in × 10.83in × 0.47in
